Alloy Steel Plate Flanges, also known as flat flanges, are simple, flat discs with bolt holes and a center bore matching the pipe's outer diameter. They are the most economical flange type, designed for low to moderate pressure applications. These flanges are welded directly to the pipe with a fillet weld on the outer rim, making them suitable for a wide range of non-critical services in various industries.

Product Description:
Characterized by their flat, disc-like shape without a raised hub. They are machined from alloy steel plates (ASTM A182 materials) and are attached to the pipe via a single fillet weld around the circumference on the backside. The face is typically Flat Face (FF) or Raised Face (RF) for lower classes.

Key Parameters:
Typically used in ASME B16.5 Class 150 and Class 300 ratings. Sizes are commonly available from 1/2" to 24" and larger. They conform to dimensional standards but are not recommended for high-stress services. Material specifications follow ASTM A182 for the relevant alloy grade.

Applications:
Widely used in water treatment plants, irrigation systems, low-pressure air and gas lines, cooling water circuits, and process lines where pressure and temperature are consistently low. They are also frequently found in utility and vent systems.

Advantages:
Lowest cost among all flange types due to simple design and less material usage. Easy to fabricate and install with basic welding skills. Lightweight, making them easy to handle and transport. Suitable for applications where cost-effectiveness is a primary concern without compromising basic sealing requirements.

Functionality:
Serves to create an accessible and sealed connection point in a piping system for inspection, cleaning, or attachment of other components. Their primary function is cost-effective fluid containment in non-critical, low-stress environments. They are not designed to handle significant bending moments or thermal shock.
