Thông tin chi tiết sản phẩm:
|
| Tên sản phẩm: | ống hợp kim 625 | loại hàn: | hàn không may smls ERW SAW SSAW LSAW |
|---|---|---|---|
| độ cứng: | HRC 30-35 | phần Shap: | Tròn/Hình vuông/Hình chữ nhật |
| Tỉ trọng: | 8,11g/cm3 | Các loại: | liền mạch |
| Gói: | Vỏ gỗ hoặc theo yêu cầu của khách hàng | Năng suất: | 5000 tấn mỗi tháng |
| kiểu: | Lắp mông hàn |
| Brand Name | TOBO |
|---|---|
| Model Number | Alloy 625 (UNS N06625) |
| Certification | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Place of Origin | China |
| Minimum Order Quantity | 1 PC |
| Price | Negotiation |
| Supply Ability | 100,000 PCS/MONTH |
| Delivery Time | 15 work days |
| Packaging Details | Regular shipping packaging or depends on customer's requirement |
| Product Name | Nickel Alloy Pipe |
|---|---|
| Model Number | Alloy 625 (UNS N06625) |
| Length | 6-12 m |
| Standard | ASTM B444 / ASTM B704 / ASTM B705 |
| Ni (Min) | 58% – 65% |
| Brand Name | TOBO |
| Section Shape | Round |
| Type | Seamless / Welded Nickel Pipe |
| Parameter | Details |
|---|---|
| Product Name | Nickel Alloy 625 Pipe |
| Material | Nickel Alloy 625 (UNS N06625) |
| Place of Origin | China |
| Standard | ASTM B444 (Seamless), ASTM B704/B705 (Welded), DIN, EN, JIS, GB |
| Outer Diameter | 6 mm – 610 mm (1/8″ – 24″) |
| Wall Thickness | 1 mm – 60 mm (Schedule 10S – XXS) |
| Length | 2 – 12 m (custom available) |
| Brand | TOBO |
| MOQ | 1 piece or 1 ton |
| Technique | Seamless (cold drawn / hot finished) or ERW / TIG welded |
| Element | Min | Max | Typical |
|---|---|---|---|
| Ni | 58.0 | 65.0 | 61.0 |
| Cr | 20.0 | 23.0 | 21.5 |
| Mo | 8.0 | 10.0 | 9.0 |
| Fe | Balance | 5.0 | 3.5 |
| Nb+Ta | 3.15 | 4.15 | 3.6 |
| Co | – | 1.0 | 0.2 |
| C | – | 0.10 | 0.03 |
| Mn | – | 0.50 | 0.20 |
| Si | – | 0.50 | 0.20 |
| P | – | 0.015 | 0.008 |
| S | – | 0.015 | 0.005 |
| Al | – | 0.40 | 0.20 |
| Ti | – | 0.40 | 0.20 |
| Density | 8.44 g/cm³ |
|---|---|
| Melting Range | 1290 – 1350°C |
| Thermal Conductivity (100°C) | 9.8 W/m·K |
| Electrical Resistivity | 1.28 µΩ·m |
| Modulus of Elasticity | 205 GPa |
| Property | Value |
|---|---|
| Tensile Strength | 830 – 1100 MPa (min 760 MPa) |
| Yield Strength (0.2% offset) | 410 – 690 MPa (min 345 MPa) |
| Elongation at Break | 30 – 50% (min 30%) |
| Hardness (HRB) | 85 – 95 |
| Impact Strength (Charpy V) | 200 J typical |
Excellent Corrosion Resistance – Outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking in chloride and sour environments.
High Strength at Elevated Temperatures – Maintains tensile strength up to 980°C (1800°F); excellent creep rupture strength.
Seawater Grade – Resists sea water corrosion without galvanic attack; proven in marine and offshore applications.
Outstanding Fatigue Resistance – High endurance limit under cyclic loading, ideal for dynamic components.
Good Workability – Can be cold formed, welded, and machined using standard methods.
Oxidation Resistance – Resists scaling up to 980°C (1800°F).
Low Magnetic Permeability – Non‑magnetic even after cold working.
Alloy 625 has a austenitic (face‑centered cubic) structure with niobium and molybdenum additions. The alloy is strengthened by precipitation of the intermetallic phase γ″ (Ni₃Nb) and carbides. This structure provides excellent ductility, weldability, and thermal stability over a wide temperature range.
Alloy 625 exhibits exceptional resistance to:
Acids – Sulfuric, hydrochloric, phosphoric, nitric, and organic acids.
Chloride environments – Pitting resistance equivalent (PRE) > 45, outperforming 316 stainless and Alloy C276 in many conditions.
Sour gas – Resists H₂S stress corrosion cracking per NACE MR0175/ISO 15156.
High temperature oxidation – Protective chromium oxide scale forms up to 980°C.
Crevice corrosion – Critical crevice temperature (CCT) > 80°C in 10% FeCl₃.
Alloy 625 pipes are widely used in extreme environments requiring both high strength and superior corrosion resistance.
Marine & Offshore – Seawater cooling lines, firewater systems, platform risers, subsea umbilicals.
Chemical Processing – Reactors, heat exchangers, evaporators, and piping for acids and chlorides.
Oil & Gas – Sour service flowlines, downhole tubing, wellhead components, flue gas desulfurization (FGD) scrubbers.
Aerospace – Hydraulic lines, engine exhaust systems, thrust reverser components.
Power Generation – Nuclear reactor components, superheater tubes, flue gas reheaters.
Pollution Control – Stack liners, dampers, and duct work for waste incineration.
Why Choosing Metal Industrial:
Sufficient Forging, Heating, Machining Equipment
In‑house Inspection Instruments for Quality Controlling (PMI, UT, ET, hydrostatic)
Competitive Price & High Quality Assurance
Fast, Effective and Efficient Services
Direct supplier of Danieli Metallurgical Equipment
Experienced Professionals on Communication
We are one of the professional manufacturers and exporters of pipeline products in China. Our company was established in 1998, the plant covers 550,000 square meters with a construction area of 68,000 square meters, employing 260 workers and 45 technicians.
We have five branch factories supplying the best quality pipes, tubes, fittings, flanges, and related accessories. We own advanced pipe production equipment including cold drawing, hot extrusion, heat treatment, and nondestructive testing (NDT) facilities. Annual production capacity exceeds 60,000 tons of pipe and fittings.
We are authorized by more than 120 top‑class mills from South Korea, Japan, and China including JFE, SUMITOMO, POSCO, BAOSTEEL, TISCO, LISCO, TPCO, HENGYANG VALIN, etc.
Packing Details: Regular shipping packaging (plywood cases, steel bundles, plastic caps on ends) or depends on customer's requirement.
Delivery Details: 7–15 days after PO for stock items; 20–30 days for production.
Q: Are you trading company or manufacturer?
A: We are a factory direct manufacturer.
Q: How long is your delivery time?
A: Generally 5–10 days if goods are in stock, or 15–25 days if not in stock, depending on quantity and specification.
Q: Do you provide samples? Is it free or extra?
A: Yes, we offer samples free of charge, but freight cost is borne by the customer.
Q: What is your terms of payment?
A: Payment ≤1000 USD, 100% in advance. Payment ≥1000 USD, 50% T/T in advance, balance before shipment. L/C at sight is also acceptable.
